Key Features

6 Line Level Inputs

Phono Input with selectable Moving Coil and Moving Magnet sensitivity settings

3 position Resistance and Capacitance settings for Phono Input

2 Line Level Outputs, one variable from 0dB to -12dB

Subwoofer OutputIndependent Headphone Amplifier

Pure Class A Gain Modules

Sealed Reed Relays for Input Switching

Heavy Gauge Steel ChassisBass and Treble Controls with Defeat Switch (bypass)

Gold Plated Sockets

12V Trigger Output

IR In and Out

Detachable Power Cord

SR 8 NAD 4 Device System remote Control

<1 watt Standby Consumption

Line Level Input

Input Impedance (R and C)
100 kilohm+ 320 pF

Input Sensitivity
158mV (ref. 500mV out)

Maximum input signal
9V

Signal/Noise Ratio, A-weighted
108dB (ref. 500mV in 500mV out, volume set to unity gain)
112dB (ref. 2V out, Volume maximum)

Frequency response
?? 0.1dB (ref. 20Hz ??20kHz, Tone defeat ON)
?? 0.5dB (ref. 20Hz ??20kHz, Tone defeat OFF)

Frequency response (subwoofer out)
100Hz (ref. -3 dB)

Output

Output Impedance
Pre-out
75 Ohm

Tape out
Source Z + 440 Ohm

Sub out
100 Ohm

Headphones
10 Ohm

Maximum Voltage Output

Pre-out
>10V into 600 Ohm

Tape out
>10V into 10 kilohm load

Sub out
>7V into 1 kilohm load

Headphones
>5V into 600 Ohm
>2V into 32 OhmHD

(CCIF IMD, DIM 100)
>0.001% dB (ref. 20Hz ??20kHz, 2V out)

Tone Controls

Treble
??5dB at 10kHz (ref. 2V in 500mV out)

Bass
??5dB at 100Hz (ref. 2V in 500mV out)

Phono Input

Input impedance

MC
40, 100, 600 Ohm (R)
1nF (C)

MM
47 kilohm (R)
220, 300, 400pF (C)

Input sensitivity

MC
0.15mV (ref. 1kHz 500mV out)

MM
2.63mV (ref. 1kHz 500mV out)

Input overload

MC
1mV/10mV/100mV (20Hz/1kHz/20kHz)

MM
16mV/147mV/1.4V (20Hz/1kHz/20kHz)

Gain ??Tape out

MC in
59.8dB1 (ref. 1kHz, 10 kilohm load)

MM in
36.5dB (ref. 1kHz, 10 kilohm load)

THD (CCIF IMD, DIM 100)
0.009% (ref. 20Hz ??20kHz, 5Vrms Tape out)

Signal/Noise ratio, IHF A-weighted

MC
78dB2 (ref. 0.5mV)

MM
86dB3 (ref. 0.5mV)

RIAA response accuracy
?? 0.5dB (ref. 20Hz ??50Hz)
?? 0.3dB (ref. 50Hz ??20kHz)

Infrasonic filter
10Hz (at -3dB)
5Hz (at -14dB)

Channel Separation
>60dB (ref 1kHz/10kHz)
>60dB (ref. 1kHz/10kHz)

Physical Specs

Dimensions (W x H x D)

Net
435 x 80 x 286mm17 1/8 x 3 x 11 1/4??/p>

Gross*
435 x 99 x 315mm17 1/8 x 3 15/16 x 12 1/2??/p>

Net weight
13.23lb (6kg)

Shipping weight
17.1lb (7.8kg)

*Gross dimensions include feet, extended buttons and rear panel terminals.
