Key Features

150W x 2 Continuous power into 8 or 4 Ohms

Bluetooth A2DP with aptX supported

MM Phono input

Analogue line inputs

USB port for service purposes

SPDIF coax and optical inputs

Speaker A, Speaker B

Preamp/Subwoofer out

Headphone amplifier

MDC Slots for future upgrades

IR remote

Smartphone Control App

12V Trigger in/out

IR in/out

RS-232 Serial port for control

Control4, Crestron, RTI, URC, AMX, Savant, Elan certified

Preamplifier

Line Input, Pre Out

THD (20Hz-20kHz)
<0.005% at 2V out

Signal/Noise Ratio
>106dB (IHF; A-weighted, ref. 500mV out, unity gain)

Channel Separation
>80dB (1kHz); >70dB (10kHz)

Input Impedance (R and C)
22 kilohm + 100pF

Maximum Input Signal
>4.5Vrms (ref. 0.1% THD)

Output Impedance
Source Z + 240 Ohm

Input Sensitivity
93mV (ref. 500mV out, Volume maximum)

Frequency Response
??0.03dB (20Hz-20kHz)

Maximum voltage output ??IHF load
>4.5V (ref. 0.1% THD)

Tone Controls

Treble: ??7.0dB at 20kHz
Bass: ??7.0dB at 60Hz
Balance: -10dB

Phono Input, Pre Out

THD (20Hz-20kHz)
<0.01% at 2V out

Signal to Noise Ratio
>84dB (200 Ohm source; A-weighted, ref. 500mV out)
>76dB (MM cartridge source, IHF; A-weighted, ref. 500mV out)

Input Sensitivity
1.44mV (ref. 500mV out, Volume maximum)

Frequency Response
??0.3dB (20Hz-20kHz)

Maximum Input Signal at 1kHz
>80mVrms (ref. 0.1% THD)

Line Input, Headphone Out

THD (20Hz-20kHz)
<0.005% at 1V out

Signal/Noise Ratio
>110dB (32 Ohm loads; A-weighted, ref. 2V out, unity gain)

Frequency Response
??0.3dB (20Hz-20kHz)

Channel Separation
>60dB at 1kHz

Output Impedance
6 Ohms

General Specifications

Continuous output Power into 4 Ohms and 8 Ohms (Stereo)
>150W (at rated THD, 20-20kHz, both channels driven)

IHF Dynamic Power
8 Ohm 250W
4 Ohm 350W
2 Ohm 400W

THD (20Hz-20kHz)
<0.02% (250mW to 150W, 8 Ohm and 4 Ohm)

Signal/Noise Ratio
>95dB (A-weighted, 500mV input ref. 1W out in 8 Ohm)

Clipping Power
>160W (at 1kHz 0.1% THD)

Peak Output Current
>20A (in 1 Ohm, 1ms)

Damping Factor
>150 (ref. 8 Ohm, 20Hz and 6.5kHz)

Frequency Response
??0.03 (20Hz-20kHz)

Channel Separation
>75dB (1kHz)
>70dB (10kHz)

Input Sensitivity (for 80W in 8 Ohm)
Line In: 490mV;
Phono In: 7.5mV;
Digital In: 24% FS

Sample Rate
up to 24 bit/192kHz

Frequency Band
2.402G ??2.480G

Maximum Transmit Power (dBm)
7dBm ??2dBm

Power Consumption
at Auto Standby ON and Network Standby OFF0.5 Watts*at Auto Standby ON and Network Standby ON1.2 Watts**OFF mode (Power switched OFF)0.1 Watts

NOTE: Bluetooth connectivity is always live when configured

Weight & Dimensions

Gross Dimensions (W x H x D)*
435 x 120 x 390mm (17 1/8 x 4 3/4 x 15 3/8)??/p>

Net Weight
11.2kg (24.7lb)

Shipping Weight
13.6kg (30lb)

*Gross dimensions include feet, extended buttons and rear panel terminals
