FiiO KA13 Portable DAC and Headphone Amplifier Dual CS43131 DAC
FiiO KA13 Portable DAC and Headphone Amplifier Dual CS43131 DAC
FiiO KA13 Portable DAC and Headphone Amplifier Dual CS43131 DAC
FiiO KA13 Portable DAC and Headphone Amplifier Dual CS43131 DAC
FiiO KA13 Portable DAC and Headphone Amplifier Dual CS43131 DAC
FiiO KA13 Portable DAC and Headphone Amplifier Dual CS43131 DAC

FiiO KA13 Portable DAC and Headphone Amplifier Dual CS43131 DAC

RM 369.00

Color :

Black
Silver
FiiO

KINDLY PM FOR LATEST STOCK AVAILABILITY BEFORE PURCHASING
1 Year Limited Warranty (subjected to Fiio T&C)

Fiio KA13 Portable DAC and Headphone Amplifier Dual CS43131 DAC PCM 768kHz 32bit DSD256

After nearly two years under fine polishing of FIIO engineers, the KA3 has been upgraded to the KA13 as a mini desktop-class DAC and headphone amplifier. It combines new design language, new technology, and robust performance, configurations and experience in one. We focus on creating a more omnipotent and comprehensive USB dongle that can provide users with a full range of high-quality experiences.

USB dongles are characterized by their small size and small output power, but the KA13 is bound to break the rules and achieve a breakthrough in power in a small space. It adopts the “Desktop Mode” which was generally seen in our high-end products to achieve robust performance nearly equal to a desktop device, and make the KA13 come with the highest output power among USB dongles.

 With the “Desktop Mode” on, the maximum sustained undistorted output power of the balanced port goes up to 550mW per channel, which is nearly equal to a desktop device, so that it can drive most headphones, allowing you to enjoy quality music in both portable and desktop use scenarios.

Listening experience is subjective, but the configuration can be truly seen, and is the basis of a good sound. We chose a better configuration for the KA13 in USB dongles at the same price range -- dual high-performance low-power consumption DAC chip CS4313 + dual low-noise op-amp chip SGM8262. The dual-core golden combo features excellent performance and indicators with superior resolution. With support for 32bit/384kHz PCM and DSD256, the KA13 despite its tiny size is capable of highly-detailed sound.

DAC chip: dual CS43131
Op-amp: dual SGM8262
Dimensions: 56.3 x 22 x 10.5 mm
Weight: 18.5 g
Supported audio formats: up to 384kHz/32bit, DSD256
USB connector: Type-C USB 2.0
Ports: 3.5 mm (single-ended), 4.4 mm (balanced), 3.5 mm coaxial out
Output power (single-ended): L+R ≥170 mW +170 mW (32 Ω/THD+N<1%)
Output power (balanced): L+R ≥ 550 mW + 550 mW (32 Ω/THD+N<1%)
NR (single-ended): ≥123 dB (32 Ω/A-weighted)
SNR (balanced): ≥ 122 dB (32 Ω/A-weighted)
Noise floor: PO<1.7μV (A-weighted); BAL<3.1 μV (A-weighted)
Output impedance (single-ended): <1.7 Ω (32 Ω load)
Output impedance (balanced): <1.8 Ω (32 Ω load)
THD+N (single-ended): <0.0005% (32 Ω)
THD+N (balanced): <0.0005% (32 Ω)
