PREAMPLIFIER SECTION LINE INPUT/PRE OUT

THD (20Hz ??20kHz)
<0.003% at 2V out

Signal-to-Noise Ratio
>100dB (IHF, A-weighted, ref. 500mV out, unity gain)

Channel separation
>85dB (1kHz)
>80dB (10kHz)

Input impedance (R and C)
47kohms + 220pF

Maximum input signal
>5.5Vrms (ref. 0.1% THD)

Output impedance
400 Ohms

Input sensitivity
82mV (ref. 500mV out, Volume maximum)

Frequency response
??0.2dB (20Hz ??20kHz)

Maximum voltage output ??IHF load
>4V (ref. 0.1% THD)

PHONO INPUT / PRE OUT

THD (20Hz ??20kHz)
<0.015% at 2V out

Signal-to-Noise Ratio
>82dB (200 Ohm source, A-weighted, ref. 500mV out)
>76dB (MM cartridge source, IHF; A-weighted, ref. 500mV out)

Input sensitivity
1.35mV (ref. 500mV out, Volume maximum)

Maximum input signal at 1kHz
>90mVrms (ref. 0.1% THD)

Frequency response
??0.3dB (20Hz ??20kHz)

LINE INPUT / HEADPHONE OUT

THD (20Hz ??20kHz)
<0.003% at 120mW

Signal-to-Noise Ratio
>90dB (32 Ohm load; A-weighted, ref. 500mV out, unity gain)

Frequency response
??0.3dB (20Hz ??20kHz)

Output impedance
2 Ohms

Maximum headphone output
32 Ohm load <8V (ref. 0.1% THD)

GENERAL SPECIFICATIONS

LINE INPUT/SPEAKER OUT

Continuous output power into 4 and 8 Ohms
60W (ref. 20Hz-20kHz at 0.03% THD, both channels driven)

THD (20Hz ??20kHz)
<0.005% (at 1W, 4 and 8 ohms)

Signal-to-Noise Ratio
>98dB (A-weighted, 500mV input, ref. 2.828V out in 4 Ohms)

Clipping power
>80W (at 1kHz 4 Ohms 0.1% THD)

IHF dynamic power
8 Ohms : 80W
4 Ohms : 150W
2 Ohms : 200W

Peak output current
>18A (in 1 Ohm, 1ms)

Damping factor
>300 (ref. 8 Ohms, 20Hz to 6.5kHz)

Frequency response
??0.3dB (20Hz ??20kHz)

Channel separation
>75dB (1kHz)
>70dB (10kHz)

Input sensitivity
260mV (for 30W in 4 Ohms)

Supports bit rate/sample rate
up to 24 bit/192kHz (digital source)
up to 24 bit/384kHz (computer source)

Standby power
<0.5W

DIMENSION AND WEIGHT

Gross dimensions (W x H x D)*
70 x 235 x 265 mm

2 13/16 x 9 5/16 x 10 7/16 inches**

Net weight
3.6kg (7.9lb)

Shipping weight
2.6kg (5.7lb)
