Shanling M3 Ultra (2022) Open Android Digital Audio Player DAP Music Player Dual ESS ES9219C BT5.0 32bit 384k DSD256 Shanling M3 Ultra (2022) Open Android Digital Audio Player DAP Music Player Dual ESS ES9219C BT5.0 32bit 384k DSD256 Shanling M3 Ultra (2022) Open Android Digital Audio Player DAP Music Player Dual ESS ES9219C BT5.0 32bit 384k DSD256
Shanling M3 Ultra (2022) Open Android Digital Audio Player DAP Music Player Dual ESS ES9219C BT5.0 32bit 384k DSD256
Shanling M3 Ultra (2022) Open Android Digital Audio Player DAP Music Player Dual ESS ES9219C BT5.0 32bit 384k DSD256
Shanling M3 Ultra (2022) Open Android Digital Audio Player DAP Music Player Dual ESS ES9219C BT5.0 32bit 384k DSD256

Shanling M3 Ultra (2022) Open Android Digital Audio Player DAP Music Player Dual ESS ES9219C BT5.0 32bit 384k DSD256

RM 2,300.00

Variant

Case Addon

Shanling
KINDLY PM FOR LATEST STOCK AVAILABILITY BEFORE PURCHASING
1 Year Limited Local Warranty (Subjected to Shanling T&C)

Introducing Shanling M3 Ultra

Same compact-sized portable player, now with an upgraded Android platform and a new audio circuit.

On the outside, M3 Ultra follows closely its predecessor. Staying at 4.2-inch screen, for the ideal balance between system usability and device portability. Aluminium frame keeps the same overall design, just with a few small adjustments, including a new solution for the MicroSD card door. And offering a standard combination of 3.5mm single-ended and 4.4mm balanced outputs.

On the inside, that’s where all the important things changed. Android platform was upgraded to the octa-core Snapdragon 665 and Android 10, refreshing M3 for swift system response and app compatibility going forward. Of course, still combined with our Android Global Lossless Output (AGLO) system for an ideal Android sound performance. We even adjusted Bluetooth, switching to a newer 5.0 version.

Audio section is still based around a pair of ESS ES9219C DACs, but M3 Ultra builds a more robust circuit around them. Two Ricore RT6863 were added to serve as dedicated headphone amplifiers, allowing the player to deal easier with the headphone load and resulting in reduced distortion, increased dynamic range and overall improved clarity. Lot of attention was also put on the used ELNA Silmic II capacitors, as they proved to be crucial in the sound tuning of the M3 Ultra, as we attempted to tune it more in the line with our house sound.

M3 Ultra overall sounds a bit warmer and more relaxed than the original M3X, while managing to improve on the technical aspects of the sound.

SPECIFICATION
Dimensions: 109mm x 70.5mm x 18mm
Weight: 199g
Screen: 4.2-inch (768x1280) Touch Screen
System: Open Android 10
Audio Formats: DSD (".iso",".dsf",".dff")/DST iSO/ ISO / DXD / APE / FLAC / WAV / AIFF / AIF / DTS / MP3 / WMA / AAC / OGG / ALAC / MP2 / M4A / AC3 / M3U / M3U8 / MQA
Hi-Res Support: up-to 32bit/384kHz, up-to DSD256
Gain Setting: Two level setting
Memory: 3GB RAM + 32GB ROM + MicroSD card slot
DAC: Dual ESS ES9219C
Digital Filters: 2 preset filters

Bluetooth: version 5.0
Bluetooth codec support: LDAC/aptX HD/aptX/SBC (as transmitter), LDAC/SBC (as receiver)

Single-ended Output:
Output Power: 41mW @32ohm (low gain), 140mW @32ohm (high gain)
Frequency Response: 20Hz-40kHz (-0.2dB)
THD+N: 0.0007%
Channel Separation: 75dB @32ohm
Dynamic Range: 121dB
SNR: 121dB
Noise: >117dB(<1.5uV) (low gain)
Output Impedance: <1ohm

Balanced Output:
Output Power: 164mW @32ohm (low gain), 260mW @32ohm (high gain)
Frequency Response: 20Hz-40kHz (-0.2dB)
THD+N: 0.0005%
Channel Separation: 115dB @32ohm
Dynamic Range: 124dB
SNR: 124dB
Noise: >114dB(<1.8uV)
Output Impedance: <1ohm
